Longot TB650L Pro | Outdoor Thermal Sight

Characteristics

Equipped with a 640×512, 12μm high-definition infrared detector with ultra-low thermal sensitivity of ≤20mK and a 50Hz high frame rate, the device captures heat sources delicately and delivers smooth images. Fitted with a 50mm large-aperture lens, it supports long-distance detection up to 2600m for human targets and 4800m for vehicle targets, perfectly adapting to long-range field reconnaissance and observation scenarios.

Built-in high-precision laser rangefinder features a 1200m maximum range and ±1m ranging accuracy to acquire target distance quickly and accurately. The intelligent automatic ballistic calculation system generates accurate impact point data after ranging, effectively assisting shooting calibration, improving hit rate and providing professional data support for every shot.

Adopting a 2560×2560 ultra-high resolution OLED screen, the device delivers exquisite and sharp imaging with fully restored image details. It is equipped with 7 color modes and 4 scene modes, which can be switched freely according to diverse environments such as day and night, rain and fog, jungle and desert, ensuring optimal imaging performance in all complex conditions.

Adopting a built-in and external dual-battery power supply system, the device achieves a continuous runtime of more than 10 hours, supporting long-term field observation and all-night duty. With 64GB large-capacity storage and recoil-activated automatic recording function, it can fully record observation and shooting processes and save key combat data completely.

Featuring innovative one-tap auto zeroing technology, the device intelligently identifies bullet impact points and completes precise zeroing with only one shot, eliminating tedious manual calibration. The rugged aluminum alloy body with IP67 all-weather protection and 1000g/ms strong shock resistance is shockproof and durable, adapting to various harsh and complex field combat environments.

Specification

Model	TB650L Pro
Detector Type	VOX
Resolution, Pixel	640×512
Pixel Size, μm	12 μm
NETD, mK	≤20mk
Frame Rate, Hz	50 Hz
Optical Characteristics
Objective lens, mm	50 mm / F0.9
Magnification, x	2.4 ×
Digital zoom, x	1x to 8x (step 1x)
Min Focus Distance, M	10 m
Exit pupil distance, mm	48 mm
Exit pupil Diameter, mm	6 mm
Field of View (H × V), degree	8.8°×7.0°
Diopter, D	-2D ~ +2D
Detection Range, m (Target size: 1.7m×0.5m)	2600 m
Detection Range, m (Verhicle)	4800 m
Rangefinder Characteristics
Wavelength,nm	905
Measuring Range,M	1000 m
Measurement accuracy,m	①5m~400m,± 1m；②＞400m,±(d*0.3%)
Electrical Characteristics
Display Type	OLED
Resolution, pixels	2560×2560
WiFi Frequency,GHz	2.4 GHz
Video/Photo fomat	mp4 / jpg
Built-in memory，GB	64 G
Power Supply，V	3.7V
Battery type*QTY/Capacity, mA	Built-in 18500 ⅹ2/2200mAh, external 18500 ⅹ1 /2200mAh
External power supply，V	5V2A
Others Characteristics
Operating time (at t=22℃）, hours	≥10 H
Operation temperature, ℃	-20℃~+50℃
Storage temperature, ℃	-40℃~+60℃
Body material	Aluminium alloy
Degree of protection, IP code (IEC60529)	IP67
Seismic coefficient, joules	1000 g/ms
Dimension（LWH), mm/inch	396 mm×82 mm×70.5 mm/15.6 in×3.23 in×2.78 in
Weight(without battery), g/oz	1045 g/36.86 oz
