Characteristics
Specification
| Model | A10 PL |
| Detector Type | VOX |
| Resolution, Pixel | 384×288 |
| Pixel Size, μm | 12 μm |
| NETD, mK | ≤35mk |
| Frame Rate, Hz | 50 Hz |
| Optical Characteristics | |
| Objective lens, mm | 50 mm |
| Magnification, x | 4× |
| Digital zoom, x | 1×、2×、3×、4× |
| Min Focus Distance, M | 5 m |
| Exit pupil distance, mm | 40 mm |
| Exit pupil Diameter, mm | 6 mm |
| Field of View (H × V), degree | 5.3°×4.0° |
| Diopter, D | -4D ~ +4D |
| Detection Range, m (Target size: 1.7m×0.5m) | 2597 m |
| Detection Range, m (Verhicle) | 4768 m |
| Rangefinder Characteristics | |
| Wavelength,nm | 905 |
| Measuring Range,M | 1000 m |
| Measurement accuracy,m | ±1 m |
| Electrical Characteristics | |
| Display Type | AMOLED |
| Resolution, pixels | 1024×768 |
| WiFi Frequency,GHz | 2.4 GHz |
| Video/Photo fomat | JPG/MP4 |
| Built-in memory,GB | 32 G |
| Power Supply,V | 3.7 v |
| Battery type*QTY/Capacity, mA | 26650 × 1/ 5000 mAh |
| External power supply,V | 5V2A |
| Others Characteristics | |
| Operating time (at t=22℃), hours | 7 H |
| Operation temperature, ℃ | -20℃~+50℃ |
| Storage temperature, ℃ | -30℃ ~ +60℃ |
| Body material | PA66 GF30 |
| Degree of protection, IP code (IEC60529) | IP67 |
| Seismic coefficient, joules | 1000 g/S² |
| Dimension(L*W*H), mm/inch | 235 mm×100 mm×62 mm9.25 in×3.94 in×2.44 in |
| Weight(without battery), g/oz | 680 g / 23.99 oz |
