Characteristics
Specification
| Model | BN60 |
| Detector Type | VOX |
| Resolution, Pixel | 640×512 |
| Pixel Size, μm | 12 μm |
| NETD, mK | ≤25mk |
| Frame Rate, Hz | 50 Hz |
| Optical Characteristics | |
| Objective lens, mm | 50 mm |
| Magnification, x | 4.1x~16.4x |
| Digital zoom, x | 1-4x |
| Min Focus Distance, M | 5 m |
| Exit pupil distance, mm | 15 mm |
| Exit pupil Diameter, mm | 7 mm |
| Field of View (H × V), degree | 8.8°×6.6° |
| Diopter, D | ±5D |
| Detection Range, m (Target size: 1.7m×0.5m) | 2600 m |
| Detection Range, m (Verhicle) | 3500 m |
| Digital night vision indicators | |
| Resolution, pixels | 1920×1080 |
| Pixel Size, μm | 4 μm |
| Frame Rate, Hz | 50Hz |
| Objective lens, mm | 35mm |
| Field of View (H × V), degree | 9.4°×7.0° |
| Magnification, x | 3.8~15.2x |
| Rangefinder Characteristics | |
| Wavelength,nm | 905 |
| Measuring Range,M | 1200 m |
| Measurement accuracy,m | ±(1+L×0.25%)(100-1200m, where L is the distance to the detection target) |
| Electrical Characteristics | |
| Display Type | 0.39-inch OLED |
| Resolution, pixels | 1024×768×2 |
| WiFi Frequency,GHz | 2.4 GHz |
| Video/Photo fomat | AVI/BMP |
| Built-in memory，GB | 64 G |
| Power Supply，V | 7.4v |
| Battery type*QTY/Capacity, mA | 18650x2 lithium battery /3.2Ah/3.7V |
| External power supply，V | 5V2A |
| Others Characteristics | |
| Operating time (at t=22℃）, hours | ≥6H |
| Operation temperature, ℃ | -25℃~+55℃ |
| Storage temperature, ℃ | -30℃～+60℃ |
| Body material | PC+ABS |
| Degree of protection, IP code (IEC60529) | IP66 |
| Dimension（L*W*H), mm/inch | 198*154*78mm7.8in*6.06in*3.07in |
| Weight(without battery), g/oz | 960g/33.86oz |
