Thermal imaging transfer aiming

Y050

Thermal imaging transfer aiming

Quick mounting and removal of attachment
    ·Quick “monocular-attachment" conversion
    ·Quick mounting and removal of attachment12um thermal imaging detector
    ·1024x768 high resolution AMOLED display
    ·No re-zeroing required and quick attached
    ·CaptureNideo recording
    ·Support APP connecting via Wi-Fi
    ·Wireless remote control
    ·Monocular's digital zoom: x1,x2,x4
    ·Degree of protection lP67
SERVICE & SUPPORT   |    CONTACT US

Characteristics

When Y050 is installed on the day scope as an infrared extension component, if the reticle of the day scope is not in the center of the infrared image, the image zeroing function can be used to shift the infrared image to ensure the position consistency between the day scope image and the infrared image.
Y050 has built-in 32GB storage space for photography and video recordingThe files ofimages and videos will be named by time, so it is recommendedto set the time in the Main Menu or synchronize the time in the Settings ofthe Longot APP before using the photography and video recordingfunction.
Y050 has a built-in Wi-Fi module, which enables the device to connect wirelessly to external devices such as smart phones.
Y050 is equipped with a professional power bank - IBP-4 battery pack (22) in the package, which is impact-resistant, waterproof and lightweight, making it perfect for outdoor use.
Y050 button module can be removed from the Y050 and installed at any position of the gun with its own accessory as a remote control.

Specification


Model
Y050
Detector TypeVOX
Resolution, Pixel
640×512
Pixel Size, μm12μm
NETD, mK≤25mk
Frame Rate, Hz≤50Hz
Optical Characteristics
Objective lens, mm
50mm/F1.0
Magnification, x

1x

Digital zoom, x

Transfer mode: ×1

Monocular telescope mode: ×1/×2/×4

Min Focus Distance, M5m
Exit pupil distance, mm/
Exit pupil Diameter, mm/
Field of View (H × V), degree8.8°×7.0°
Diopter, D/
Detection distance, m (target size :1.7 m ×0.5 m)2600m
Detection distance, m ((Vehicle :2.3 m ×2.3 m)3000m
Recognition distance, m (target size :1.7 m ×0.5 m)1229m
Electrical Characteristics
Display Type
OLED
Resolution, pixels1024×768
WiFi Frequency,GHz2.4GHz
Video/Photo fomatmp4/jpg
Built-in memory，GB32 GB
Power Supply，V3.7v
Battery type*QTY/Capacity, mABuilt-in battery 3100+ IBP-6 power pack × 2
External power supply，V5V2A
Others Characteristics
Operating time (at t=22℃）, hours
≥4h+7h
Operating temperature, ℃-20℃~+50℃
Storage temperature, ℃-30℃~+60℃
Body materialMagnesium alloy
Degree of protection, IP code (IEC60529)IP67
Seismic coefficient, joules800g/ms
Dimension（L*W*H), mm/inch

146*62*73mm5.74in*2.44in*2.87in

Weight(without battery), g/oz530g/18.69oz
