Longot A6 Pro THERMAL SIGHTS

LGT A6 Pro

Longot A6 Pro THERMAL SIGHTS

The wide view and easy operation will make your outdoor life get more fun
    ·12μm detector
    ·19mm objective len
    ·LCOS display
    ·Physical distance measurement
    ·Msensor
    ·950m detective range
    ·IP66 waterproof
Application： Night Patrol Personal Security Search and Rescue Outdoor Adventure
SERVICE & SUPPORT   |    CONTACT US

Characteristics

Vanadium oxide sensor uses advanced passive infrared thermal imaging technology. Its 256*196 resolution with 50Hz frequency sensitivity detector offer experience excellent visual effects；
The image is smooth, high definition, highlighting target. The background is rich and the recognition is high. Different image modes can be switched according to different environments to achieve the effect of high recognition of the target is prominent；
Every machine has passed strict earthquake resistance test；
connect external display or power bank for long battery Life

Demonstrate

Application

Specification


Model
A6PRO
Detector TypeVox
Resolution, Pixel256×192
Pixel Size, μm12μm
NETD, mK≥50mk
Frame Rate, Hz≤30Hz
Optical Characteristics
Objective lens, mm19mm
Magnification, x2.3x
Digital zoom, x1x、2x、3x、4x
Min Focus Distance, M/Y5m
Exit pupil distance, mm45mm
Exit pupil Diameter, mm6mm
Field of View (H × V), degree9.2° × 6.9°
Diopter, D-5D ~ +5D
Identify distances, m (Target size: 1.7m×0.5m)467 m
Electrical Characteristics
Display Type
LCOS
Resolution, pixels1280×960
WiFi Frequency,GHz2.4GHz
Video/Photo fomatJPG/MP4
Built-in memory，GB32G
Power Supply，V3V or 3.7V
Battery type*QTY/Capacity, mACR123 × 2
External power supply，V5V2A
Others Characteristics
Operating time (at t=22℃）, hour
4hrs
Operating temperature, ℃/℉-10℃~+50℃
Storage temperature, ℃/℉-20℃~+60℃
Body materialPA66 GF30
Degree of protection, IP code (IEC60529)IP67
Felt recoil，G/ms6000J/ms
Dimension（L*W*H), mm/inch

187mm × 61mm × 59mm7.36in×2.40in×2.32in

Weight(without battery), g/oz< 380g/13.40oz
