Specification
| Model | A7PRO |
| Detector Type | Vox |
| Resolution, Pixel | 384×288 |
| Pixel Size, μm | 17μm |
| NETD, mK | ≥50mk |
| Frame Rate, Hz | ≤30Hz |
| Optical Characteristics | |
| Objective lens, mm | 25mm |
| Magnification, x | 1.44x |
| Digital zoom, x | 1x、2x、3x、4x |
| Min Focus Distance, M | 5m |
| Exit pupil distance, mm | 45mm |
| Exit pupil Diameter, mm | 6mm |
| Field of View (H × V), degree | 14.9°×11.2° |
| Diopter, D | -5D ~ +5D |
| Identify distances, m (Target size: 1.7m×0.5m) | 433m |
| Electrical Characteristics | |
| Display Type | LCOS |
| Resolution, pixels | 1280×960 |
| WiFi Frequency,GHz | 2.4GHz |
| Video/Photo fomat | JPG/MP4 |
| Built-in memory，GB | 16G |
| Power Supply，V | 3V or 3.7V |
| Battery type*QTY/Capacity, mA | CR123 × 2 |
| External power supply，V | 5V2A |
| Others Characteristics | |
| Operating time (at t=22℃）, hours | 3.5hrs |
| Operating temperature, ℃/℉ | -10℃~+50℃ |
| Storage temperature, ℃/℉ | -20℃~+60℃ |
| Body material | PA66 GF30 |
| Degree of protection, IP code (IEC60529) | IP67 |
| Felt recoil，G/ms | 6000J/ms |
| Dimension（L*W*H), mm/inch | 176mm×61mm×61mm6.93in×2.40in×2.40in |
| Weight(without battery), g/oz | <420g/14.81oz |
